2. Installation
42 RC700 / RC90 Option Fieldbus I/O Rev.14
20. Select [File]-[Download in Flash] from the applicomIOR console menu. Register the
configuration to the Fieldbus master board.
Make sure that the flash memory of Fieldbus master board stores the configuration;
otherwise the Fieldbus master board cannot correctly function. Also, you cannot
control it from EPSON RC+7.0.
If you changed the configuration, select [File]-[Download in Flash]
from the
applicomIOR console
menu and register the configuration to the fieldbus master
board.
21. After few seconds, the display of “Configured boards state” on the status bar turns to
green.
Now, the Fieldbus master board is ready to operate in the master mode.
22. Close the “applicomIO Console” application.
23. Refer to the next section EPSON RC+7.0 Configuration and continue the step.

NOTE
