SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 176
SE Group Confidential (Related Staff Only)
Figure 3-117. Removing the Waste Ink Tube (4)
Waste Ink Tube
Joint Tank
Hole
Larger clamp
