SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 199
SE Group Confidential (Related Staff Only)
AFTER REPLACEMENT
1. Install the eight ink cartridges for service. (p207)
2. Lower the lock levers.
3. Turn on the printer.
4. Discard the waste ink.
5. Select Initial ink charge.
Select All channels, and press the [Run] button to perform the initial ink charge.
(p334)
6. Select Nozzle Check.
Select Nozzle Check Pattern Print, and press the [Run] button to perform the
nozzle check. (p311)
7. Perform cleaning if necessary. (p313)
8. Select Switch between Ink cartridges and Ink tanks.
Select All channels and Ink Tank, and press the [Run] button to validate the ink
tanks. (p329)
9. Turn off the printer.
10. Remove the eight ink cartridges for service. (p207)
11. Install the ink tanks.
(p207)
12. Lower the lock levers.
13. Turn on the printer.
14. Confirm that there are no errors.
To Next Page
