SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 220
SE Group Confidential (Related Staff Only)
5. Push the Driven Roller Holder below, and install the Driven
Roller Assy steadily.
Driven Roller Holder
Driven Roller Assy
