SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 223
SE Group Confidential (Related Staff Only)
Figure 3-173. Removing the Suction Fan
Frame
Rolled A4 paper
Holes
- Bottom side-
Clamp
Suction Fan
Relay Connectors
Screwdriver
Cable
Rolled A4 paper
B
Suction Fans
