Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
ADJUSTMENT Overview 269
SE Group Confidential (Related Staff Only)
Board related
parts/units
Main Board
(NVRAM backup OK)
Before
replacement
1 Raise up the slider’s levers. ---
√
---
2 Remove Slider & chip unit ---
√
---
3 Turn the power on in Serviceman mode. ---
√
---
4 NV-RAM backup
√√
--- p. 282
Replacement 5 Replacement ---
√ √
p. 123
After
replacement
6 Turn the power on in Firmware update mode. ---
√
---
7 Model Selection (at service program)
√√
---
8 Update the firmware.(automatically power off)
√√
--- p. 291
9 Turn the power on in Serviceman mode. ---
√
---
10 NVRAM Clear OK ---
√
---
11 Select HDK/nB on Control Panel ---
√
---
12 Main Board initial setting. (automatically power off)
√√
--- p. 342
13 Install slider and chip unit ---
√
---
14 Lower the slider’s levers ---
√
---
15 Turn the power on in FIrmware update mode ---
√
---
16 NV-RAM restore
√√
--- p. 282
17 Turn the power off ---
√
---
18 Turn the power on in normal mode. ---
√
---
19 Model Selection (at service program)
√√
---
20 RTC & USB ID Input
√√
--- p. 343
21 Reset the Main Board exchange counter.
√√
--- p. 346
22
Verify that the date/time settings are correct on the control
panel.
---
√
---
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired
(Reattached) Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
