Epson SC-F9200 series Service Manual

SC-F9200 Series Revision B
MAINTENANCE When left unused/transportation 371
SE Group Confidential (Related Staff Only)
5.3.2.2 Preparation after transportation (Without replacing Ink
Tanks)
REQUIRED TOOLS
 Stubby screwdriver
 Screwdriver
 Brand-new ink tank (x8)
 Brand-new chip unit (x8)
 Media (for nozzle checking)
 Service program
 Communication Driver
PROCEDURE
1. Remove all the cleaning cartridges. (Page 207)
2. Lower all the lock levers.
3. Start the printer in the Serviceman Mode.
Turn on the printer while pressing [Menu] + [Back] + [OK].
4. Start the service program and select Treatment for transfer (After transfer
without replacement Ink Tank) from ADJUSTMENT (Sequence).
5. Select Switch between Ink cartridges and Ink tanks.
Select All channels and Ink Tank, and press the [Run] button to make the ink
tank available. (Page 329)
6. Turn off the printer.
7. Install the ink tanks. (Page 207)
8. Install the chip units, and pour ink.
9. Turn on the printer.
10. Discard the waste ink.
11. Select Initial ink charge.
Select All channels, and press the [Run] button to run the initial ink charge.
(Page 334)
12. Select Nozzle Check.
Select Nozzle Check Pattern Print, and press the [Run] button to run the nozzle
check. (Page 311)
13. Perform cleaning if necessary. (Page 313)
C H E C K
P O I N T
Within two weeks since the preparation, install the ink tank and
chip unit previously used.
If two weeks or more has passed since the preparation before
transportation was carried out, Refer to Preparation after
transportation (With replacing Ink Tanks) (p.372)
C H E C K
P O I N T
Install the ink tank and chip unit previously used.
