Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
TROUBLE SHOOTING Remedies for Service Call Error 52
SE Group Confidential (Related Staff Only)
159A
ATC Motor
overload error
Overcurrent to the ATC Motor was detected.
 ATC Motor cable disconnection.
 Irregular load
 ATC Motor encoder failure
 ATC Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 ATC Motor to Sub-F Board (CN602)
2. Does the ATC Motor encoder work properly?
Check it using the Service Program.
Replace the ATC Motor. (Page 241)
159B
ATC Motor
over speed error
The ATC Motor was driven at a speed faster than a
predetermined one during deceleration.
 Irregular load
 ATC Motor encoder failure
 Sub-F Board failure
 APG Motor driver failure
Does the ATC Motor encoder work properly? Check
it using the Service Program.
1. Replace the ATC Motor. (Page 241)
2. Replace the Sub-F Board. (Page 239)
3. Replace the Main Board. (Page 123)
159C
ATC Motor
reversing error
The number of occurrences of reversing the ATC
Motor has reached a predetermined limit.
 The polarity of ATC Motor cable is opposite.
 ATC Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 ATC Motor to Sub-F Board (CN602)
2. Does the ATC Motor encoder work properly?
Check it using the Service Program.
Replace the ATC Motor. (Page 241)
159D
ATC Motor
driving time-out error
Abnormally-long driving duration of the ATC Motor
was detected.
 Irregular load
 Firmware becomes out of control.
---
Replace the Main Board. (Page 123)
159E
ATC Motor
velocity deviation error
The APG Motor was driven at a speed abnormally
faster than a predetermined one during acceleration or
deceleration.
 Irregular load
 ATC Motor encoder failure
 ATC Motor failure
 Sub-F Board disconnection
 ATC Motor driver failure
Does the ATC Motor encoder work properly? Check
it using the Service Program.
1. Replace the ATC Motor.
(Page 241)
2. Replace the Sub-F Board. (Page 239)
3. Replace the Main Board. (Page 123)
Table 2-4. Troubleshooting for Service Call Error
Code Error Name Cause Check Item Remedy
