SC-F9200 Series Revision C
TROUBLE SHOOTING Remedies for Print Quality Troubles 63
SE Group Confidential (Related Staff Only)
Bandings in the paper feeding direction.
The Print Head has not been adjusted
properly.
---
Carry out the following adjustments.
CR Direction Head Slant Adjustment (Page
314)
PF Direction Head Slant Adjustment (Page
319)
The paper was not fed properly.
---
Carry out the following adjustment.
Feed amount adjustment
Check the following settings.
Feed Adjustment
Media Tension
PF Scale or PF Encoder failure
1. Is the PF Scale damaged or contaminated?
2. Is the PF Scale attached properly?
3. Is the PF Encoder installed correctly?
1. Clean the PF Scale.
2. Reinstall the PF Scale and PF Encoder.
3. Replace the PF Scale
(Page 216) and PF
Encoder
(Page 215).
The tension of the PF Timing Belt is not
proper.
---
Correct the tension of the PF Timing Belt.
(Page
338)
PF Motor failure
---
Replace the PF Motor. (Page 213)
Table 2-5. Print Quality Troubles
Symptom Cause Check Item Remedy
To Next Page
