Epson SC-F9200 series Service Manual

SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Parts Diagram 91
SE Group Confidential (Related Staff Only)
Figure 3-12. Additional Drying Fan Unit (Option)
 Drying Fan Unit (p. 252)
 Drying Fan Cover (p. 254)
 Sub-I Board (p. 255)
Relays the connection between the Main Board and the Drying
Fan Unit. See “6.1 Block Wiring Diagram (p390)” for specific
connections to the concerning parts/components.
 Drying Fan Power Supply Board (p. 256)
Generates the DC voltage for the Drying Fan Unit from the AC power supply.
 Drying Fan (p. 257)
Drys up the printed media.
