SC-S30600 Series Revision B
DISASSEMBLY & ASSEMBLY Parts Diagram 75
Confidential
Figure 3-11. Additional Drying Fan Unit (Option)
 Drying Fan Unit (p. 192)
 Drying Fan Cover (p. 194)
 Sub-I Board (p. 195)
Relays the connection between the Main Board and the Drying
Fan Unit. See “6.1 Block Wiring Diagram (p291)” for specific
connections to the concerning parts/components.
 Drying Fan Power Supply Board (p. 196)
Generates the DC voltage for the Drying Fan Unit from the AC power supply.
 Drying Fan (p. 197)
Drys up the printed media.
