3.2.11.18 Middle Frame Unit Removal
1. Remove the printer mechanism unit. (See Section 3.2.6.)
2. Remove the Paper eject frame unit. (See Section 3.2.11.6
3. Remove the pump unit. (See Section 3.2.11.7)
4. Remove the edge guide.(See Section 3.2.11.8
5. Remove the CR unit. (See Section 3.2.11.14.)
6. Remove the LD shaft. (See Section 3.2.11.15.)
7. Remove the PF roller. (See Section 3.2.11.16.)
8. Remove 1 screw (CBS, 3x6) securing the LD frame guide to the middle frame unit.
9. Remove the connector cable for the middle frame from the clump.
10. Remove 2 screws (CBS, M 3X6) securing the middle frame to the bottom frame assembly and 1 screw
(CBS, 3x8) fixing the ink cartridge holder base. Then remove the middle frame unit.
Bottom Main Frame
Middle Frame Unit
CBS Screws (3X6)
CBS Screw (3X8)
Flange Nut
LD Guide Frame
Rear Paper Guide Assembly
Edge Guide Unit
Figure 3-36. Middle Frame Removal
