Epson STYLUS 3000 Service Manual

EPSON Stylus COLOR 3000
Rev. A
3-
3
3.2 Disassembly and Assembly
This section describes procedures for disassembling and assembling the major units and parts.
Read CAUTION in Section 3.1.1 prior to disassembling the printer.
CAUTION
Upper Case Removal
ROM Replacement
Printer Mechanism
Removal
Printhead Removal
HP Sensor Removal
PWS Paper Width
Sensor Removal
Main Board Removal
PSB/PSE Board
Removal
PL Sensor Removal
Waste Ink Drain
Pad Removal
Printer Mechanism
Disassembly
CR Unit Removal
LD Roller Shaft
Removal
PF Roller Shaft
Removal
Rear Paper Guide
Removal
Middle Frame
Assembly Removal
Ink Cartridge Holder
Removal
Ink End Sensor
Removal
Cartridge Sensor
Removal
Edge Guide Unit
Removal
Paper Quantity Sensor
Removal
Release Sensor
Removal
Front/Rear PE Sensor
Removal
CR Motor Removal
Pump Motor Removal
Paper Eject Frame
Removal
Pump Unit Removal
ASF PW Sensor
Removal
PF Motor Removal
Start
Figure 3-1. Printer Disassembly Procedures
