EPSON Stylus COLOR 3000
Rev. A
4-11
Select "4. Gap" from the
adjustment program.
The printer prints the adjustment
pattern in the LQ and SLQ
modes.
Change the value
using key.
Press "Space" key to
print.
Press "0" key to correct
the value.
The printer prints another
adjustment pattern in the LQ and
SLQ modes.
Press "Return" key.
Gap Width
Change the value
using key.
What
does the pattern
show?
Yes
No
Is the head gap
OK?
Is the
head gap
OK?
Yes
No
Yes
Is the
value
correct?
End
Start
No
Figure 4-7. Head Gap Adjustment Flowchart
