Epson STYLUS 3000 Service Manual

EPSON Stylus COLOR 3000
Rev. A
1-1
9
Reverse Channel

Transmission mode
IEEE-1284 nibble mode

Adaptable connector
Same as forward channel

Synchronization
Refer to the IEEE-1284 specification

Handshaking
Refer to the IEEE-1284 specification

Data transmission timing
Refer to the IEEE-1284 specification

Signal level
IEEE-1284 level 1 device
See forward channel.
Table 1-23 shows the connector pin assignment and signals for reverse channel of the parallel interface.
Pin No. Signal Name
Return
GND Pin
I/O Description
1 HostClk 19 I Clock si
g
nal from the host computer.
2-9 DATA 0-7 20-27 I
These signals represent parallel data on
bits 2 to 9. Each signal is High when the
data is logical 1 and LOW when the data
is logical 0.
10 PtrClk 28 O Clock signal from the printer
11
PtrBusy /
Data bits 3,7
29 O
Busy signal from the printer.
Data bit 3 or 7 in reverse channel.
12
AckDatareq /
AckData Bits 2,6
28 O
Acknowledge request signal.
Data bit 2 or 6 in reverse channel.
13 Xflag/Data bit 1,5 28 O
X flag signal.
Data bit 1 or 5 in reverse channel.
14 HostBusy 30 I Busy signal from the host computer
31 /INIT 30 I Not used
32
/Data Avail /
Data bits 0,4
29 O
Data available signal.
Data bit 0 or 4 in reverse channel.
36 1284-Active 30 I 1284 active signal.
18 Logic-H - O Pulled up to +5V via 3.9 K-ohm resistor.
35 +5V - O Pulled up to +5V via 3.3 K-ohm resistor.
17 Chassis GND - - Chassis ground for the printer.
16,33,19-30 GND - - Signalground.
15,34 NC - - Not connected.
Note)
1. */* at the beginning of a signal means active low.
2. The I/O column indicates the direction of the signal as viewed form the printer.

Extensibility Request
The printer responds affirmatively when the extensibility request values are 00H or 04H, as follows:
 00H Request Nibble Mode Reverse Channel Transfer.
 04H Request Device ID using Nibble Mode Rev Channel Transfer

Device ID
The printer sends following device ID string upon request:
 [00H] [xxH]
 MFG EPSON;
 CMD ESCPL2, PRPXL, BDC;
 MDL Stylus [SP]COLOR[SP] 3000;
 CLS PRINTER;
Note) [00H] denotes a hexadecimal values of zero.
Table 1-23. Connector Pin Assignment and Signals (Reverse Channel)
