DISASSEMBLY AND ASSEMBLY Overview 116
4.1.3 Work Completion Check
If any service is made to the printer, use the checklist shown below to confirm all
works are completed properly and the printer is ready to be returned to the user.
Table 4-2. Check List
Classification Part Check item Check column
Printer unit Self test Operation is normal? VOK / VNG
On line test Print is normally done? VOK / VNG
Print Head (nozzle
check pattern print)
Ink gets out normally from all the
nozzles?
VOK / VNG
CR mechanism
CR smoothly operates? VOK / VNG
CR makes abnormal sound during its
operation?
VOK / VNG
Paper loading
mechanism
Paper is smoothly loaded? VOK / VNG
Paper jam does not happen? VOK / VNG
Paper does not warp during paper
loading?
VOK / VNG
Multiple papers are not fed? VOK / VNG
Abnormal sound is not heard during
paper loading?
VOK / VNG
There is no alien substance at paper
route?
VOK / VNG
Scanner unit Mechanism Glass surface is not dirty? VOK / VNG
Alien substance is not mixed in the
CR movement area?
VOK / VNG
CR mechanism CR smoothly operates? VOK / VNG
CR operates together with scanner
unit?
VOK / VNG
CR makes abnormal sound during its
operation?
VOK / VNG
LED LED normally turns on and white
reflection test is done near home
position?
VOK / VNG
On line test On line test
Operation is normal?
VOK / VNG
Copy Copy Local copy is normal? VOK / VNG
Adjustment Designated
adjustment items
Adjustment condition is suitable? VOK / VNG
Lubrication Designated
lubrication items
Lubrication is done at designated
place?
VOK / VNG
Lubrication volume is suitable? VOK / VNG
Function Firmware version The newest version VOK / VNG
Dispatch
packing
Ink cartridge Ink cartridge is normally installed? VOK / VNG
Waste Ink Pads Remained life of waste ink pads are
sufficient?
VOK / VNG
Protection during
distribution
Printer CR is in the cap position? VOK / VNG
Others Attached goods All of attached goods from users are
packed?
VOK / VNG
Table 4-2. Check List
Classification Part Check item Check column
