EPSON Stylus CX3500/CX3600/CX3650/CX4500/CX4600 Revision A
APPENDIX Parts List 197
7.4 Parts List
Table 7-16. Stylus CX3500/CX3600/CX3650/CX4500/CX4600
Code Parts Name
100 COVER,ASF
101 COVER,REAR;ECG
102 COVER,USB;ECG
103 HOUSING,CARD SLOT;ECG
104 COVER,CARD SLOT;EFS
105 PAPER SUPPORT ASSY.
106 HOUSING,UPPER ASSY.
107 LOCK,SCANNER;ECG
108 STACKER ASSY.
110 COMPRESSION SPRING,5.1
111 FOOT
112 LOCK,STACKER
113 HOUSING,LOWER;ECG
114 PANEL UNIT
116 BUTTON,COPY;EBM3
117 BUTTON,POWER;EBM3
118 BUTTON,S;EBM3
119 SHEET,PANEL;B
120 SPRING,COVER,CARD SLOT
450 BOARD ASSY.,PANEL
506 POROUS PAD,CAP,LOWER
540 POROUS PAD,JOINT,LOWER
546 POROUS PAD,INK EJECT,1
547 POROUS PAD,INK EJECT,2
548 POROUS PAD,INK EJECT,3
549 POROUS PAD,INK EJECT,4
550 POROUS PAD,INK EJECT,5
551 POROUS PAD,INK EJECT,6
552 POROUS PAD,INK EJECT,7
553 POROUS PAD,INK EJECT,8
800 SCANNER UNIT
801 SPRING,CIS
802 MOTOR ASSY.,SC
803 CIS
804 FFC,CIS
806 COVER,DOCUMENT ASSY.
807 MAT,COVER,DOCUMENT
809 HINGE,ASSY.
810 CR,MAIN
811 HINGE,L
200 MAIN BOARD ASSY.;C
300 POWER SUPPLY UNIT;100V;B
451 HARNESS
500 PRINTER MECHANISM(ASP)MAK10-100
501 FRAME,FRONT
502 COVER,CABLE,HEAD
503 COVER,CARTRIDGE
504 FRAME,HOLDER,FFC
Table 7-16. Stylus CX3500/CX3600/CX3650/CX4500/CX4600
Code Parts Name
