EPSON Stylus CX3500/CX3600/CX3650/CX4500/CX4600 Revision A
APPENDIX Parts List 198
505 SCALE,PF
507 POROUS PAD,TUBE,UPPER
508 GUIDE,FFC
510 ASF UNIT
511 C.B.P-TITE SCREW,3X6,F/ZN-3C
512 CONNECTER,CSIC
513 BOARD ASSY.,CSIC
514 GROUNDING SPRING,PF
515 FRAME,GUIDE,CR
516 LEVER,PARALLEL ADJUSTMENT,RIGHT
517 LEVER,PARALLEL ADJUSTMENT,LEFT
518 TORSION SPRING,SHAFT,CR,GUIDE
519 PRESSING SPRING,SHAFT,CR,GUIDE
520 SCALE,CR
521 EXTENSION SPRING,3.289
522 PAPER GUIDE,FRONT,SUPPORT
523 INK SYSTEM ASSY.
524 MOTOR ASSY.,PF
525 ROLLER,PF ASSY.
526 PAPER GUIDE,UPPER ASSY.
527 PAPER GUIDE,FRONT ASSY.
528 HOLDER,SHAFT ASSY.
529 TORSION SPRING,0.22
530 BOARD ASSY.,DETECTOR
531 CR ASSY.
Table 7-16. Stylus CX3500/CX3600/CX3650/CX4500/CX4600
Code Parts Name
532 CABLE,HEAD
533 BOARD ASSY.,ENCORDER
534 BOARD ASSY.,DETECTOR,PW
535 MOTOR ASSY.,CR
536 DETECTOR ASSY.,PG
537 PRINT HEAD
538 CLAMP,TUBE
539 LEVER,PG
541 TUBE,INK EJECT
542 JOINT,INK EJECT
543 MOUNTING PLATE,LEVER,PG
544 TORSION SPRING,19.01
545 C.B.P-TITE SCREW,3X10,F/ZN-3C
554 COMPRESSION SPRING,2.51
555 EXTENSION SPRING,0.143
556 TORSION SPRING,6.45
Table 7-16. Stylus CX3500/CX3600/CX3650/CX4500/CX4600
Code Parts Name
