EPSON Stylus Photo R1900/R2880/R2000/R2000s/SC-P400 Series Revision I
Operating Principles PG Setting 33
2.4 PG Setting
As this printer uses an Auto PG (APG), an appropriate PG position is set according to the used paper type.
The following table indicates the PG positions, the main applications of each position, and the relationships between the two sensors used with the APG.
Note "*": The signal output is “High” while the PG positions are changed.
Table 2-4.
Application
PG Position
PG (– –) PG (–) PG (Typ) PG (+) PG (++) Release
Printing Photo paper
(A4,Letter)
Roll paper
Photo Matte paper
Plain paper
Exclusive paper
PG (-) rub avoidance
Envelope
PG (Typ) rub avoidance
CD/DVD
Non-printing
Standby position after
power-on (When the
CDR Tray Base is
closed.)
At power-off
Ink Mark Sensor reading.
(Auto Bi-D)
Ink Mark Sensor reading.
(Detection of dot
missing)
Initialization at power-on
Cleaning (wiping)
Ink Cartridge
replacement
Standby state for CD/
DVD feeding
Paper jam removal
PG value 1.05mm 1.20mm 1.70mm 2.10mm 4.50mm
Sensor PG (– –) PG (–) PG (Typ) PG (+) PG (++) Release
APG Sensor 1* Low Low Low Low Low Low
APG Sensor 2 Low Low Low Low High High
