EPSON Stylus Photo R1900/R2880/R2000/R2000s/SC-P400 Series Revision I
Disassembly And Assembly Overview 77
4.1.7 Disassembly
The flowchart below lists the step-by-step disassembly procedures. When disassembling each unit, refer to the page number shown in the figure.
Figure 4-6. Disassembly Flowchart
Rear Housing
(p.79)
Start
Front Decoration
Plate Left/Right
(p.79)
Panel Unit (p.80)
Paper Support Assy
(p.78)
Decoration Plate
Left/Right (p.82)
Panel Unit (p.80)
Front Decoration
Plate Left/Right
(p.79)
Cover Open Sensor
(p.138)
Upper Housing /
Printer Cover
(p.83)
Upper Housing
Support Assy
(p.85)
Lower Housing /
Printer Mechanism
(p.98)
Board Assy (Main
Board/Power Supply
Board) (p.86)
High Voltage Module
(p.89)
LED Board (p.88)
APG Assy (p.91)
CR Scale (p.92)
CR Motor (p.131)
PF Encoder (p.134)
Printhead /
CSIC Assy
(p.94)
Paper EJ Frame
Assy / Front Cover /
CDR Tray Base
(p.114)
CDR Release Lever
Sub Assy (p.116)
Ink System Unit
(p.118)
CDR Sensor (p.136)
Front Paper Guide / Paper
EJ Roller / Front Paper
Guide Pad Tray (p.121)
PF Encoder (p.134)
Upper Paper Guide
Assys (p.129)
PF Roller Shaft
(p.124)
Ink Mark Sensor /
PW sensor (p.135)
CR Encoder (p.134)
Carriage Shaft /
Carriage Unit
(p.100)
APG Assy (p.91)
LED Board (p.88)
CR Scale (p.92)
Upper Paper
Guide Assys
(p.129)
PE Sensor Holder
(p.137)
FLAG Release Assy
(p.128)
Release Holder Assy
(p.127)
APG Assy (p.91)
ASF Assy (p.108)
PE Sensor Holder
(p.137)
ASF Motor (p.133)
PF Motor (p.132)
Waste Ink Pad /
Waste Ink Tube Left/
Right (p.112)
Front Paper Guide
Pad (p.111)
Foot (p.113)
PictBridge Holder
Assy (p.113)
C H E C K
P O I N T
 The boxes shown in a dotted-line are not the shortest
procedures, but are necessary to proceed to the next step.
 Since a prototype was used to illustrate these disassembly
and assembly procedures, the appearance of some parts
may differ from those on an actual product.
 Stylus Photo R1900 was used to illustrate these
disassembly and assembly procedures. The appearance of
some parts differ from those on Stylus Photo R2880,
however, there is no difference in the procedures.
Stacker Assy
(p.78)
