4.1.2 Orientation Definition
The terms used for indicating the orientation/direction throughout this chapter are as
follows.
Figure 4-1. Orientation Definition
C A U T I O N
The cutter blade is razor-sharp. Be especially careful when
handling the cutter.
Carbide blade employed for the cutter blade is hard but brittle.
Be careful not to hit it against metal parts of the printer as it
can be easily damaged.
When you removed any parts (especially cables) that are
secured with acetate tape or two-sided tape, be sure to reinstall
and secure them with the tape as exactly the same as they were.
Disassembling the frame and some components of the printer is
prohibited because they are assembled with precise
measurements in 1/100 mm unit at the factory.
When moving the Carriage Unit manually, make sure to
remove paper.
Up
Down
Left
Rear
Right
Front
