Epson Stylus Pro 9900 - Check Adjustments Results

Epson Stylus Pro 7700/7710/7700M/7710M/7900/7910/9700/9710/9900/9910/WT7900/WT7910/9890/9908/7890/7908 Revision I
ADJUSTMENT Check Adjustments Results 443
Confidential
5.10 Check Adjustments Results
This allows you to print all the adjustment values.
PAPER USED
 Size: A3
 Type: Plain Paper
PROCEDURE
1. Turn the printer ON in the Serviceman Mode.
Turn the power ON while pressing [Menu ] + [Paper Feed ] + [OK]
simultaneously.
2. Select SELF TESTING
→ Mecha Adjustment → Print Adj. Variable →
Printing.
3. Press [OK] while [Enter] Print is displayed.
The adjustment values will be printed.
Figure 5-116. Print Sample
