Epson Stylus Pro 9900 - Parts List

Epson Stylus Pro 7700/7710/7700M/7710M/7900/7910/9700/9710/9900/9910/WT7900/WT7910/9890/9908/7890/7908 Revision I
APPENDIX Parts List 481
Confidential
8.4 Parts List
NOTE : This Parts List is for Epson Stylus Pro 7900/7910/9900/9910. Some
of the items differ from Epson Stylus Pro 7700/7710/7700M/7710M/
9700/9710/WT7900/WT7910/9890/9908/7890/7908, therefore refer
to Service Parts Information as necessary.
Epson Stylus Pro 9900/9910
Table 8-2. Epson Stylus Pro 9900/9910
Ref No Part Name
1 PIPE,BASKET,CENTER,ASP
2 ARM,BASKET,ASP
3 BASKET ASSY,ASP
4 POWER CABLE
5 PAPER GUIDE BOTTOM,ASP
6 BOX,MANUAL,ASP
7 STAND RIGHT UNIT,ASP
8 STAND LEFT UNIT,ASP
9 STAY STAND ASSY,ASP
10 SHAFT,BASKET,ASSY.
11 CASTER,P-60-HT
12 CASTER,P-60-HTS
13 JOINT,PIPE,BASKET,FRONT,ASP
14 PIPE,BASKET,FRONT,SIDE,ASP
15 PIPE,BASKET,UPPER,ASP
16 JOINT,PIPE,BASKET,REAR,LEFT,ASP
17 JOINT,PIPE,BASKET,REAR,RIGHT,ASP
18 HOLDER,PIPE,BASKET,FRONT
19 HOLDER,PIPE,BASKET,REAR
20 PAD,CR
21 MOUNTING PLATE,PAPER GUIDE,BOTTOM
22 SCREW ASSY.,ASP
24 STAND,UNIT,44,ESL,ASP
100 SHAFT,COVER,IC,LEFT,UNIT,ESL,ASP
101 SHAFT,COVER,IC,RIGHT,UNIT,ESL,ASP
102 STOPPER,COVER,FRONT
103 GROUNDING PLATE,ROLL
104 COVER,FRONT,RIGHT,UNIT,ESL,ASP
105 COVER,FRONT,LEFT,UNIT,ESL,ASP
107 COVER ROLL ASSY. ASP
108 COVER,IC,RIGHT,UNIT,ESL,ASP
109 COVER,IC,LEFT,UNIT,ESL,ASP
110 LABEL,ROLL PAPER SET,PAPER GUIDE LOWER
111 COVER FRONT,ASP
112 LOGO PLATE,86.5X21.6
113 CATCH,STRIKER
114 STRIKER,SENSOR
115 COVER,FRONT,RIGHT,ASP
116 COVER,FRONT,LEFT,ASP
117 COVER,REAR,LEFT,ASP
118 COVER,SIDE,ROLL,LEFT
119 COVER,SIDE,ROLL,RIGHT
120 COVER,TOP,BASE,SUPPORT,RIGHT
121 COVER,ROLL,SUPPORT,RIGHT,ASP
122 COVER,ROLL,SUPPORT,LEFT.,ASP
137 LABEL,ULTRA CHROME INK,HDR
138 LABEL,MODEL NAME;B
139 HANDLE
140 COVER,TOP,BASE,ASP
200 BOARD ASSY.,MAIN
201 BOARD ASSY.,SUB
202 BOARD ASSY.,SUB
203 BOARD ASSY.,SUB
204 BOARD ASSY.,SUB
300 POWER SUPPLY UNIT,B,ASP
301 HARNESS,ASP
Table 8-2. Epson Stylus Pro 9900/9910
Ref No Part Name
