Epson Stylus Pro 9900 - Page 482

Epson Stylus Pro 7700/7710/7700M/7710M/7900/7910/9700/9710/9900/9910/WT7900/WT7910/9890/9908/7890/7908 Revision I
APPENDIX Parts List 482
Confidential
302 FAN ASSY.,ASP
501 GUIDE ROLL PAPER,L,UNIT,B,ESL,ASP
502 MOUNTING PLATE COVER ROLL PAPER LEFT,ASP
503 REWIND,UNIT,ESL,ASP
504 RAIL GUIDE ROLL PAPER,ASP
505 SENSOR,PE.;UNIT,ESL,ASP
506 PHOTO INTERUPTER,TLP1243(C8)
507 CABLE,DETECTOR,HP,CR,ASP
508 DETECTOR,PAPER THICKNESS,UNIT,ESL,ASP
509 PANEL,UNIT,ESL,ASP
510 HARNESS,PANEL,ASP
511 GUIDE,ROLL,PAPER,RIGHT,UNIT,ESL,ASP
512 PULLEY,DRIVEN,UNIT,44,ESL,ASP
513 SCALE,CR,ASP
514 MOTOR ASSY.,CR.,ASP
515 HOLDER,ASSY.,IC,RIGHT,ESL,ASP
516 HOLDER,ASSY.,IC,LEFT,ESL,ASP
517 PLUNGER,ASSY,ASP
518 HARNESS,RELAY,HEAD,RIGHT,ASP
519 HARNESS,RELAY,HEAD,LEFT,ASP
520 CR,UNIT,B;ESL,ASP
521 BOARD ASSY.,INK MARK
522 COVER,CR,MAIN
523 PRINT HEAD
524 HARNESS,HEAD,A,ASP
525 HARNESS,HEAD,B,ASSY,ASP
526 SELECTOR,UNIT,ESL,ASP
527 VALVE ASSY.,HEAD,ASP.
528 SENSOR,COVER,FRONT,RIGHT,UNIT,ESL,ASP
529 SENSOR,COVER,FRONT,LEFT,UNIT,ESL,ASP
530 CLAMP,TUBE
531 HOLDER TUBE,ASP
Table 8-2. Epson Stylus Pro 9900/9910
Ref No Part Name
532 HARNESS,DRV,RIGHT,UPPER,ASP
533 HARNESS,CR,ASP
534 HARNESS,DRV,RIGHT,LOWER,ASP
535 TUBE ASSY.,SUPPLY,INK;B,ASP
536 TUBE ASSY.,SPPLY,INK,A,ASP
537 HOLDER,WHEEL,EJ,LOWER,UNIT,ESL,ASP
538 COVER,CUTTER,UNIT,ESL,ASP
539 CATCH
540 PAPER,EJECTION,ROLLER,PE,UNIT,ESL,ASP
541 FRAME,RAIL,CUTTER,UNIT,44,ESL,ASP
542 CABLE CLAMP
543 GUIDE,COVER,ROLL PAPER,SUPPORT
544 CLUMP,TUBE,DUCT
545 CLIP,DUCT,INK EJECT,LARGE
546 CLIP,DUCT,INK EJECT,SMALL
547 POROUS PAD,PLATEN
548 CABLE,FAN,RIGHT,ASP
549 CABLE,FAN,MIDDLE,ASP
550 HARNESS,MAINTENANCE TANK,RIGHT,ASP
551 PUMP ASSY.,PRESSURIZING,UNIT,ESL,ASP
552 TUBE,PRESSURIZING,RIGHT,ASP
553 TUBE,PRESSURIZING,LEFT,44,ASP
554 LEAF SPRING,LOCK
555 EJECT,GUIDE,UNIT,ESL,ASP
556 POROUS PAD ASSY.,INK EJECT,A,ASP
557 MOTOR ASSY., RELEASE, ASP
558 CABLE,MOTOR,RELEASE,ASP
559 HARNESS,ASP
560 APG,UNIT,ESL,ASP
561 CABLE,MOTOR,APG,ASP
562 HARNESS,RELAY,SUB,B,UPPER,ASP
563 HARNESS,RELAY,SUB,B,LOWER,ASP
Table 8-2. Epson Stylus Pro 9900/9910
Ref No Part Name
