Epson Stylus Pro 7700/7710/7700M/7710M/7900/7910/9700/9710/9900/9910/WT7900/WT7910/9890/9908/7890/7908 Revision H
PRODUCT DESCRIPTION Control Panel 76
Confidential
Mecha Adjustment Pk Nozzle/Alignment Cleaning CL3 Runs the check function of nozzle and alignment. From pattern printing to
cleaning can be executed from this menu.
*Epson Stylus Pro 7900/7910/9900/9910
only.
Init.Fill
SSCL
A/B (C/M) CL1
CL2
CL3
CL4
C/D (Bk/Lk) CL1
CL2
CL3
CL4
E/F (Or/Gr)* CL1
CL2
CL3
CL4
G/H (LLk/Y) CL1
CL2
CL3
CL4
I/J (Lm/Lc) CL1
CL2
CL3
CL4
IM Sensor Gap Adjusts the gap of the Ink Mark Sensor.
FAN Operates the Suction Fan.
Temporary PG Unlocks the carriage lock and caps the Printhead.
PF Head Slant Adjusts the slant of the Printhead to the PF.
CR Head Slant Adjusts the slant of the Printhead to the CR.
Menu Explanation
