T3-B T6-B Maintenance 17. Calibration
T-B series Maintenance Manual Rev.1 133
(4) Reset the encoder. Click the <Yes> button.
(5) Controller (Manipulator) restarts.
* This window will disappear when the Controller starts up.
(6) Select the reference point to use for calibration, and click the <Next> button.
Select a point from the
current points to use for
checking the accuracy.
(7) Click the <Jog…> button to display the [Jog & Teach] dialog.
