Epson TM-H6000IV

32
Slip (validation) printing
Receipt printing (80 mm paper width)
• In 2-divided energizing, the print position within the printable area of the thermal
elements for dots 1 to 256 and 257 to 512 is shifted approximately 0.07 mm {0.0028"} as
shown in the figure below.
• In 4-divided energizing, the print position within the printable area of the thermal
elements for dots 1 to 128, 129 to 256, 257 to 384, and 385 to 512 is shifted
approximately 0.04 mm {0.0016"} as shown in the figure below.
85.4 5.6
32.818.4
Bottom margin
[units: mm (All the numeric values are typical.)]
[units: mm (*: typical)]
7
9
.5 ±
0
.5
72.2*
3.7 ± 2.0
25
25
51
Approx. 0.07 mm



Approx. 0.04 mm
