36
Electrical Characteristics
Supply voltage DC 24V ± 7%
Ripple voltage: 300 mVpp or less (for models
with MICR reader)
Current consumption
(when using the PS-
180 at 24V)
Standby Mean: Approximately 0.1 A
Operating Slip printing Mean: Approximately 1.7 A
Receipt printing Mean: Approximately 1.8 A
Note: When print ratio is approximately 18%
• Continuous printing for 50 lines (repeating
20H-7FH)
∗ Font A, 42 columns, ASCII character
• 5 line feeding
• Autocutting
If printing is continuously performed with a high ratio, the overcurrent protection may be
activated and result in uneven print density or a low voltage error. Therefore, the printing
length must not exceed the following values when printing with high print ratio.
Print ratio: Number of dots being energized per one dot line/Total number of dots per one
dot line (512 dots)
#$%&'
$%&'
42 columns
Print ratio 80% 100%
Print example
Print length 30 mm 20 mm
58 mm
72 mm
