Epson TM-H6000IV - For Ethernet Interface

Chapter 2 Setup
59
2
For Ethernet Interface
Connect the printer to a network by a LAN cable via a hub.
Ethernet interface connection diagram
The modular cable is connected to the cash drawer.
10/100BASE-T
TM-H6000IV
Serial cable
Modular
cable
Cash drawer
DM-D
Power supply unit
+ AC cable
Power supply unit
+ AC cable
