Changing the Paper Width
The printer is initially set to print on 80 mm {3.15"} width paper, but you can change the printer
to print on 58 mm {2.28"} width paper by installing the optional roll paper guide.
Follow the steps below to install the roll paper guide.
1
Open the roll paper cover.
2
Align 3 projections on the paper guide with the holes in the roll paper
holder, and push it until it clicks into place.
• Because some parts of the print head and the autocutter contact the platen and they
may become worn out in 58 mm printing, once you change the paper width from 80 mm
to 58 mm, you cannot change it back to 80 mm.
• When changing the paper width, be sure to change the setting for the paper width with
the customized value. To set the customized value, see "Setting the Memory Switches/
Receipt Enhancement" on page 65
