DIP Switch Bank 2
SW Function ON OFF
Initial
setting
2-1 Handshaking (BUSY condition) Receive buffer full
• Offline
• Receive buffer full
OFF
2-2
Customer display (DM-D)
connection
Connected Not connected OFF
2-3 ∼
2-4
Selects print density
See "Selecting the Print Density (DIP
Switches 2-3/2-4)" on page 51.
OFF
2-5 ∼
2-6
Reserved Fixed to OFF OFF
2-7 I/F pin 6 reset signal Enabled Disabled OFF
2-8 IF pin 25 reset signal Enabled Disabled OFF
For DIP switch 2-1 (BUSY condition), see also "Selecting the BUSY Status" on page 52.
