141
Appendix
AC Adapter
Option Specifications
Wireless LAN Cable Set (OT-WL01)
Customer Display (DM-D110 )
For details on the specifications of the DM-D110, refer to the "DM-D110/DM-D210 Technical
Reference Guide".
Input conditions Input voltage (rating): AC 100V to 240V
Frequency (rating): 50 to 60 Hz
Input current (rating): 1.3A
Output conditions Output voltage (rating): DC 24V ± 5%
Output current (rating): 2.0A
Wireless module ELPAP07: 802. 11b/g/n wireless LAN Module (Epson)
Standard IEEE802.11b/g/n (Wi-Fi certificated)
SSID 1 to 32 alphanumeric characters
Connection mode Ad hoc mode, Infrastructure mode
Authentic method, Encryption algorithm Open+WEP, Shared+WEP, WPA-PSK+TKIP, WPA-PSK+AES,
WPA2-PSK+AES, WEP64, WEP128, TKIP, AES
Power voltage DC 4.5V to 5.5V
Current consumption 300 mA at maximum
Frequency range 2.4 GHz band
Potential interference range 40 m
Overall dimensions Wireless LAN unit: Approx. 24 × 51 × 10 (W × D × H)
USB extension cable: 1 m (length)
