41
Chapter 2 Setup
2
Installation Procedures
1
Turn off the product.
2
Clean and dry the printer case where the optional external buzzer will be
installed.
3
With 2 pieces of the affixing tape combined, peel off the sticker on one
side, and paste it around the center of the attaching surface of the
optional external buzzer.
4
Connect the cable of the optional external buzzer to the drawer kick
connector on the product.
Connect and disconnect the optional external buzzer while the product is turned off. If
you connect it while the product is turned on, the buzzer does not function correctly.
Do not connect both the optional external buzzer and the drawer by using a splitter or
similar device.
To Next Page
