6 7
TM-U220A
Specification
(For Argentina Fiscal)
1.8 Print Area
1) Roll paper width and print area
Maximum 200 dots,
400 positions
(6.8)
(5.8)
63.4
76
(NOTE 2)
NOTE 1
27
34.9
Cutting position (autocutter)
Cutting position (manual cutter)
[Units: mm]
Left margin: 6.8 mm
Right margin: 5.8 mm
Printable area: 63.4 mm (Maximum 200 dots, 400 positions)
NOTES: 1. The values shown in the figures are the distance between the manual cutter and the
print position.
2. The values shown for the printable area in the figure are the values calculated
(between dot centers) based on the wire diameter (0.29 mm {0.0011"}).
Figure 1.8.1 Print Area
1.9 Internal Buffer
1) Receive buffer 4 KB
2) NV (Non-volatile) bit image data area: 128 KB
3) User NV memory: 8 KB
1.10 Electrical Characteristics
1) Supply voltage: Built-in power supply
2) Operating voltage: Input: AC100 V to 240 V
Printer drive voltage: DC+24 V (Supplied by the built-in power supply.)
3) Power consumption (except while driving the drawer kick-out):
Operating: ANK model: Mean: 31 W
Standby: Mean: 2.2 W
