TM-U220A
Specification
(
For Ar
g
entina Fiscal
)
30 29
Table 3.3.2 DIP Switch 2
Switch
no.
Function ON OFF Default
1 Selection of number of
characters per line (cpl) (*)
42 cpl / 35 cpl 40 cpl / 33 cpl Off
2 Reserved (Autocutter) Enabled Disabled On
3 Undefined -- -- Off
4 Selection of serial
communication set
By memory
switch
By DIP switch Off
5 Undefined -- -- Off
6 Reserved
(Flash memory rewriting)
Enabled Disabled Off
7 Pin 6 reset signal Used Not used Off
8 Pin 25 reset signal Used Not used Off
(*) Selection of dots between characters: On = 2 half dots, Off = 3 half dots
The number of characters per line in the Table indicates for the 76 mm-width paper.
3.3.4 Memory switches
The memory switches covers the following settings:
• Function of the memory switches Msw2, Msw8
• Customized values
• Communication conditions of the serial interface
1) Memory switches
Table 3.3.5 Memory Switch Msw2
Switch no. Function 48 (Off) 49 (On) Default
1 Undefined -- -- Off
2 Undefined -- -- Off
3 Selection of the character
code system of Simplified
Chinese
GB18030 GB2312 Off
4 Undefined -- -- Off
5 Undefined -- -- Off
6 Undefined -- -- Off
7 Undefined -- -- Off
8 Undefined -- -- Off

Epson TM-U220A Specifications

General

Print Method	9-pin, serial impact dot matrix
Number of Pins	9 pins
Copy Capability	Original + 2 copies
Print Width	63 mm
Paper Thickness	0.06 to 0.085 mm
Print Speed	4.7 lps
Interface	Parallel
Number of Columns	40
Data Buffer	4 KB
Power Supply	AC adapter (included)
Character Set	95 Alphanumeric, 128 x 12 Graphic
Paper Width	76 mm, 69 mm, 57.5 mm
