TM-U220A
Specification
(For Argentina Fiscal) 44
45
A
DLE EOT n
[Name] Transmit real-time status
[Format] ASCII DLE EOT n
Hex 10 04 n
Decimal 16 4 n
[Range] 1 ≤ n ≤ 4
[Description] • Transmits the real-time status.
n Function
1 Transmits printer status.
2 Transmits offline cause status.
3 Transmits error cause status.
4 Transmits roll paper sensor status.
• This printer transmits the following status in real time.
• Printer status (n = 1)
Bit Off/On Hex Decimal Status
0 Off 00 0 Fixed.
1 On 02 2 Fixed.
2 Off 00 0 Drawer kick-out connector pin 3 is LOW.
On 04 4 Drawer kick-out connector pin 3 is HIGH.
3 Off 00 0 Online.
On 08 8 Offline.
4 On 10 16 Fixed.
5, 6 -- -- -- Reserved.
7 Off 00 0 Fixed.
• Offline cause status (n = 2)
Bit Off/On Hex Decimal Status
0 Off 00 0 Fixed.
1 On 02 2 Fixed.
2 Off 00 0 The roll paper cover is closed.
On 04 4 The roll paper cover is opened.
3 Off 00 0 Paper is not being fed with the paper FEED
button.
On 08 8 Paper is being fed with the paper FEED button.
4 On 10 16 Fixed.
5 Off 00 0 No paper-end stop.
On 20 32 Printing stops due to paper end.
6 Off 00 0 No error.
On 40 64 Error occurred.
7 Off 00 0 Fixed.

Epson TM-U220A Specifications

General

Print Method	9-pin, serial impact dot matrix
Number of Pins	9 pins
Copy Capability	Original + 2 copies
Print Width	63 mm
Paper Thickness	0.06 to 0.085 mm
Print Speed	4.7 lps
Interface	Parallel
Number of Columns	40
Data Buffer	4 KB
Power Supply	AC adapter (included)
Character Set	95 Alphanumeric, 128 x 12 Graphic
Paper Width	76 mm, 69 mm, 57.5 mm
