Page #65 background imageLoading...
Page #65 background image
Confidential
EPSON
TITLE
SHEET
REVISION
NO.
SHEETNEXT
TM-U220A
Specification
(For Argentina Fiscal) 55
56
A
ESC a n
[Name] Select justification
[Format] ASCII ESC a n
Hex 1B 61 n
Decimal 27 97 n
[Range] 0 n 2, 48 n 50
[Default] n = 0
[Description] In standard mode, aligns all the data in one line to the position.
n Justification
0, 48 Left justification
1, 49 Centering
2, 50 Right justification
ESC c 4 n
[Name] Select paper sensor(s) to stop printing
[Format] ASCII ESC c 4 n
Hex 1B 63 34 n
Decimal 27 99 52 n
[Range] 0 n 255
[Default] n = 0
[Description] Selects the paper sensor(s) Whether to use to stop printing or not when a paper end
is detected.
(n)
Bit Off/On Hex Decimal Function
0 Off 00 0 Disables roll paper near-end sensor.
On 01 1 Enables roll paper near-end sensor.
1 Off 00 0 Disables roll paper near-end sensor.
On 02 2 Enables roll paper near-end sensor.
2 7
Off 00 0 Reserved.
[Note] If the printer is not equipped with the optional roll paper near-end sensor, the printer
does not stop with this command even though the roll paper near-end sensor is
enabled.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson TM-U220A and is the answer not in the manual?

Epson TM-U220A Specifications

General IconGeneral
Print Method9-pin, serial impact dot matrix
Number of Pins9 pins
Copy CapabilityOriginal + 2 copies
Print Width63 mm
Paper Thickness0.06 to 0.085 mm
Print Speed4.7 lps
InterfaceParallel
Number of Columns40
Data Buffer4 KB
Power SupplyAC adapter (included)
Character Set95 Alphanumeric, 128 x 12 Graphic
Paper Width76 mm, 69 mm, 57.5 mm
