GS ( E pL pH fn [parameters]
[Name] Set user setup commands
[Description] • Controls the user setting modes.
• pL, pH specify (pL + pH ×256) as the number of bytes after pH (fn and [parameters]).
• fn specifies the function.
• [parameters] specify the process of each function.
fn
Format
Function
No.
Function
1
GS ( E p
L pH fn d1 d2
1 Change into the user setting mode.
2
GS ( E p
L pH fn d1 d2 d3
2 End the user setting mode session.
3
GS ( E p
L pH fn
[a1 b18...b11] ... [ak
bk8....bk1]
3 Changes the memory switch.
4
GS ( E p
L pH fn a
4 Transmit the settings of the memory
switch.
11
GS ( E p
L pH fn a d1...dk
11 Sets the configuration item for the serial
interface.
12
GS ( E p
L pH fn a
12 Transmits the configuration item for the
serial interface.
[Notes] • Frequent write command executions by an NV memory write command may damage
the NV memory. Therefore, it is recommended to limit writing the commands into the
NV memory to 10 times or less a day.
• If the power is turned off while this command is being executed, the printer may go
into an abnormal condition. Be careful not to turn the power off while this command
is being executed.
• While processing this command, the printer may become BUSY while writing data to
the NV memory and stops receiving data. Therefore, be sure not to transmit data
from the host PC while the printer is BUSY.
• After transmitting <Function 1, 4, 6, and 12>, do not transmit the subsequent data until
the status is received.
<Function 1> GS ( E pL pH fn d1 d2 (fn = 1)
[Format] ASCII GS ( E pL pH fn d1 d2
Hex 1D 28 45 pL pH fn d1 d2
Decimal 29 40 69 p
L pH fn d1 d2
[Range] (p
L + pH × 256) = 3 (pL = 3, pH = 0)
fn = 1
d1 = 73
d2 = 78
[Description] • Enters the user setting mode and transmits a notice of the change of mode.
To Next Page
