Hardware Control and Troubleshooting
Table 39 Output Fields for the show hardware Command
Field Description
Voltage • N/A—Voltage is not applicable for this unit.
• NOT OK—Voltage for this card is outside its operating range.
• OK—Voltage for this card is within its operating range.
Temperature • Cold—Temperature is colder than normal.
• Extreme—Temperature is much hotter than normal.
• Hot—Temperature is hotter than normal.
• N/A—Temperature does not apply to this unit.
• Normal—Temperature is within normal operating range for this unit.
(1) A line card is configured with the card command (in global configuration mode); it might not be installed.
Table 40 Product Code for SmartEdge 600 Chassis
Product Code Chassis Model
H1 SmartEdge 600 chassis.
This command displays information only for those units that are installed in
the chassis, and in most cases, displays only the fields that are applicable to
the type of card.
Table 41 Output Fields for the show hardware Command with the detail Keyword
Field Description
Active Alarms
(1)
Alarm conditions for this unit:
• NONE—No alarm conditions exist.
• condition—Alarm condition is in effect.
For a complete list of conditions that can cause an alarm, see the Troubleshoot with System
Power and Alarm LEDs section.
Card Status For line cards only:
• FPGA mismatch—Card needs an FPGA upgrade.
• FPGA upgrade—FPGA upgrade has been started.
• HW detected—Card is detected and being initialized.
• HW failure—Card has experienced a failure.
• HW initialized—Card is initialized and ready.
Chass Entitlement Type of chassis for which this card is intended:
• All—Card is entitled in every chassis.
• List of chassis, separated by slashes (/)—Listed chassis only.
Chassis Type SE600—SmartEdge 600 chassis.
DimFpga rev DimFpga file rev Dim FPGA revision and file revision; N/A or not displayed if not applicable for this card.
EEPROM id/ver nnnn/n—Version of the unit EEPROM.
EPPA memory nnn MB—Size of ingress and egress PPA memory.
5727/153 30-CRA 119 1170/1 Uen A | 2010-04-09
