SmartEdge 600 Router Hardware Guide
Table 41 Output Fields for the show hardware Command with the detail Keyword
Field Description
Fan Tray Status • Present—Fan tray is installed.
• Not Present—Fan tray is not installed or not working.
Fan(s) Status • Failed—At least one fan is not working.
• Normal—All fans are working.
FlipFpga rev FLIP FPGA revision and file revision; N/A or not displayed if not applicable for this line card.
ForteFpga rev Forte FPGA revision and file revision; applicable to XCRP only. This FPGA controls power on/reset
for all devices.
Hardware Rev n—Hardware revision level for this unit; single digit.
HubFpga rev
HubFpga file rev
Hub FPGA revision and file revision; N/A or not displayed if not applicable for this card.
IPPA memory nnn MB—Size of ingress and egress PPA memory.
ITU ch International Telecommunications Union (ITU) channel number (corresponds to the wavelength
displayed in the Wavelength field); not displayed if not applicable for the transceiver installed
in this port.
LEDs State of Fail, Active, Standby, and Sync LEDs:
• Blink—ODD test is in progress.
• On—LED is lit.
• Off—LED is not lit.
Sync LED is for controller cards only.
LimFpga rev LIM FPGA revision and file revision; N/A or not displayed if not applicable for this line card.
MAC Address nn:nn:nn:nn:nn:nn—Medium access control (MAC) address of the system (stored in the
EEPROM); displayed using the backplane keyword only.
MaxFpga rev Max FPGA revision and file revision; applicable to XCRP controller card only. This FPGA controls
access to the CPU bus.
Memory Memory for which this controller card is entitled:
• Max—All memory on the controller card is enabled.
• nnnn MB—Size in MB of enabled memory.
Mfg Date dd/mm/yyyy—Date this unit was manufactured.
MinnowCPLD Ver Minnow CPLD revision; applicable to the SmartEdge 100 chassis slot 1 only.
ODD Status Status of the on-demand diagnostics (ODD) tests:
• Aborted—The session was terminated by the user or by the standby controller card being
removed.
• Incomplete—At least one of the requested tests could not be run.
• In-progress—Session is currently in progress.
• Not available—No session of the ODD has been run for this unit.
• Passed—All tests have passed.
• n Failure(s)—One or more tests have failed.
OpusFpga rev Opus FPGA revision and file revision; applicable to XCRP only. This FPGA manages peripherals
such as the front panel LEDs and the CRAFT ports.
58 27/153 30-CRA 119 1170/1 Uen A | 2010-04-09
