2 MENUS
The control panel uses several different menus:
S Main menu
S Configuration menu
S Tools menu
S Weld data setting menu
S Measurements menu
S Weld data memory menu
S Fast mode menu
The menu trees are displayed on page 54 and onwards. During start−up, a start−up
screen containing information about the current program version is displayed briefly.
Start−up screen
2.1 Main menu
In the MAIN MENU,
you can change weld-
ing process, wire type,
control method, wire di-
mension etc.
You can access other
sub menus from this
menu.
SAW
PROCESS SAW
REGULATION TYPE CA
WIRE TYPE Fe SOLID
WIRE DIMENSION 0.8 mm
CONFIGURATION"
TOOLS"
SET MEASURE MEMORY
FAST
MODE
