2.1.4 Measurements menu
Main menu
In MEASURE, you can view measured values for various welding parameters while
welding is in progress.
A 450 AMP
Measured welding
current
30.0 Volt
Measured arc voltage
50 cm/min
Measured travel speed
SAW: CA
A 450 Amp
V 30.0 Volt
50 cm/min
|
|
|
|
|
|
NONE NONE
GAS /
FLUX NONE
2ND
FUNCT
300 cm/min
Measured wire feed
speed
30 kJ/cm
Indicates energy per
unit length, which is
obtained using the
values selected for
welding current, arc
voltage and travel
speed
SAW: CA
50 cm/min
300 cm/min
30.0 kJ/cm
|
|
|
|
|
|
NONE NONE
GAS /
FLUX NONE
2ND
FUNCT
The measured values remain in the display even after welding has been completed.
You can move to different menus without losing the measurement values.
The settings knobs can be used to change the welding parameters in the
measurement display.
If the set value is changed when welding is not in progress, the measurement value
changes to zero.
