8.3.1 Product code
In the PRODUCT
CODE menu it is poss-
ible to select the auto-
matic welding machine,
column and boom,
roller bed or positioner
to be used.
MACHINE CONFIGURATION
PRODUCT CODE A2TFX
WIRE FEED AXIS"
TRAVEL AXIS"
TANDEM OFF
QUIT
When selecting product code, the correct motor type and gear ratio for the used
gearbox in the relevant product are selected automatically.
The following options can be selected:
S A2TFJ1
A2 tractor automatic welding machine for Submerged Arc Welding (SAW)
S A2TGJ1
A2 tractor automatic welding machine for Gas−Shielded Metal Arc Welding
(GMAW)
S A6TFF1
A6 tractor automatic welding machine for Submerged Arc Welding (SAW)
S FREE 2 AXIS
Optional configuration for connecting 2 motors to the actuator board. One for
wire feed and one for travel motion.
S FREE 3 AXIS
Optional configuration for connecting external roller beds, positioners or linear
axis as well as for 2 motors to the actuator board. One for wire feed and one for
travel motion.
8.3.2 Wire feed axis
The wire feed motor is set automatically according to the tables below.
A2TFJ1 A2TGJ1 A6TFF1
Motor 5035 38 RPM 5035 68 RPM VEC4000
Gear 1 49:1 49:1 156:1
Gear 2 1:1 1:1 1:1
Diameter feed rollers 49 mm 49 mm 49 mm
Pulse sensor 28 ppr 28 ppr 32 ppr
Low manual speed 150 cm/min 150 cm/min 150 cm/min
High manual speed 300 cm/min 300 cm/min 300 cm/min
