When you press RESET, all counters are reset. Date and time show the most recent
reset.
If you do not reset the counters, these are all automatically reset when one of them
has reached its maximum value.
Maximum counter values
Time 999 hours, 59 minutes, 59 seconds
Weight 13350000 grams
Quantity 65535
9.7 Quality functions
Main menu Tools Quality functions
Quality functions keep track of various interesting weld data for individual welds.
These functions are:
S Time of welding start.
S Duration of welding.
S Maximum, minimum and average current during welding.
S Maximum, minimum and average voltage during welding.
S Maximum, minimum and average energy per unit length during welding.
The number of welds since the most recent reset is displayed in the row at the
bottom. Information can be stored about a maximum of 100 welds. In the event of
more than 100 welds, the first one is overwritten.
The most recently noted weld is presented in the display, although it is also possible
to browse between other noted welds. All logs are deleted when you press RESET.
QUALITY FUNCTIONS
#WELD: 1 / 4
START 20090107 15:59:14
WELD TIME 00:00:20 WELD DATA:
HEAT INPUT: 3.12 kJ/mm
MAX MIN AVE.
I (Amp) 293.00 243.00 289.00
U (V) 41.50 16.20 39.40
Q (kJ/min) 7.00 0.00 2.00
NUMBER OF WELDS SINCE RESET: 4
RESET UPDATE
QUIT
