− 51 −
bi24d1ea
9.7.1 Store quality data
Main menu Tools Export / Import
The files that are produced in the control panel are stored as xml files. The USB
memory must be formatted as FAT32 in order to work.
Insert a USB memory in the control panel, see chapter 9.3 “File manager”.
Select QUALITY
FUNCTION LOG, press
EXPORT.
EXPORT/IMPORT
WELD DATA SETS
SYSTEM SETTINGS
SETTING LIMITS
MEASURE LIMITS
ERROR LOG
QUALITY FUNCTION LOG
PRODUCTION STATISTICS
EXPORT
QUIT
The entire set of quality data (information about the 100 most recent welds) that is
stored in the control panel is now saved on the USB memory.
The file is in a folder called QData. QData is created automatically when you insert a
USB memory.
9.8 Calendar
Main menu ! Tools ! Calendar
Date and time are set here.
Select the row that is to
be set: year, month,
day, hour, minutes and
seconds. Set the
correct value using one
of the setting knobs.
Press SET.
DATE & TIME
YEAR 2008
MONTH NOV
DAY 21
HOUR 10
MINUTES 45
SECONDS 55
20081121 10:48:59
SET QUIT
GB
