ESAB PEK A2 - Settings for Gouging with CW; Function Explanations; CA, Constant Welding Current; CW, Constant Wire Feed

− 21 −
bi24d1ea
Settings Value after
resetting
In steps ofSetting range
Setting limits − − −
Measure limits − − −
*) The setting range is dependent on the product used.
5.2 Settings for gouging with CW
Settings Setting range In steps of Value after
resetting
Arc voltage* 14 − 50 V 0.1 V (1V) 30 V
Wire feed speed* 0 − 2500 cm/min 1 cm/min 300 cm/min
Travel speed* 0 − 200 cm/min 1 cm/min 50 cm/min
Welding direction Y − J − J
Start data
Air pre−flow 1.0 − 99.0 s 0.1 s 0 s
Start type Direct or Scrape − Direct
Wire creep start Auto or Set speed − Auto
Wire creep start speed 0 − 1000 cm/min 1 cm/min 20 cm/min
Start phases OFF or ON − OFF
Open−circuit voltage OFF or ON − OFF
Maximum open−circuit voltage 5 − 60 V 0.1 V 50 V
Stop data
Air post−flow 1.0 − 99.0 s 0.1 s 0 s
Crater filling OFF or ON − OFF
Crater filling time 0 − 10 s 0.01 s 1 s
Burnback time 0 − 10 s 0.01 s 1 s
Stop phases OFF or ON − OFF
Dynamic regulation OFF or ON − ON
Setting limits − − −
Measure limits − − −
*) The setting range is dependent on the product used.
6 FUNCTION EXPLANATIONS
6.1 CA, constant welding current
The wire feed is controlled by the power source so that a constant welding current
can be achieved.
− Constant current value can be selected in the main menu.
6.2 CW, constant wire feed
The welding current is a result of the selected wire feed speed.
− Constant wire feed can be selected in the main menu.
GB
