− 45 −
bi24d1ea
Select the row with the
information that is to be
transferred. Press
EXPORT or IMPORT,
depending on whether
the information is to be
exported or imported.
EXPORT/IMPORT
WELD DATA SETS
SYSTEM SETTINGS
SETTING LIMITS
MEASURE LIMITS
ERROR LOG
QUALITY FUNCTION LOG
PRODUCTION STATISTICS
EXPORT IMPORT
QUIT
9.3 File manager
Main menu Tools File manager
In the file manager it is possible to manage information on a USB memory (C:\). File
manager makes it possible to delete and copy weld data and quality data manually.
When the USB memory is connected, the display shows the memory’s default folder
if one is not previously selected.
The control panel remembers where you were the last time you used file manager,
so that you return to the same place in the file structure when you come back.
FILE MANAGER
..
NEW FOLDER
QData.xml
INFO UPDATE
ALT. QUIT
S In order to ascertain how much storage space remains for the memory, use the
INFO function.
S Update the information by pressing UPDATE.
S When you want to delete, change name, create new folder, copy or paste, press
ALT. A list then appears from which you can choose. If (..) or a folder is selected,
you can only create a new folder or paste in a file that you have previously
copied. If you have selected a file, the options RENAME, COPY or PASTE will be
added if you have previously copied a file.
GB
