− 32 −
bi24d1ea
The following menu appears:
In this example we
change the welding
current from 400 A to
500 A.
Press QUIT twice.
SAW WELD DATA SETTING
VOLTAGE 20.0 V
CURRENT 500 A
TRAVEL SPEED 0 cm/min
DIRECTION J
START DATA"
STOP DATA"
DYNAMIC REGULATION ON
SETTING LIMITS"
MEASURE LIMITS"
QUIT
The setting for weld data number 5 has now been edited and stored.
8 CONFIGURATION MENU
Main menu Configuration menu
This menu contains the following sub−menus:
S Language, see chapter 1.2.1 “Choice of language”
S Code lock, see chapter 8.1
S General settings, see chapter 8.2
S Machine settings, see chapter 8.3
S Cable length, see chapter 8.4
S Maintenance, see chapter 8.5
8.1 Code lock
Main menu Configuration menu Code lock
When the lock function is activated and you are in the measure screen, remote
mode or fast mode menu, a password (lock code) is required to exit from these
menus.
CODE LOCK
LOCK STATUS OFF
SET / CHANGE LOCK CODE
QUIT
Code lock is activated in the configuration menu.
GB
