Then scroll to the next row, ASSOCIATED WELD DATA. Here you can browse
through the weld data sets that are stored in the weld data memory. Selected the
desired weld data number using the setting knobs. Press STORE to save. To delete
the stored set, press DELETE.
8.2.2 Quality data log to file
In the QUALITY DATA
LOG TO FILE menu it
is possible to activate it
with ON.
GENERAL CONFIGURATION
FAST MODE SOFT BUTTONS 1
QUALITY DATA LOG TO FILE ON
SOFT KEYS SETUP"
AUTO SAVE MODE OFF
UNIT OF LENGTH METRIC
QUIT
Read more about settings for the quality function in chapter 9.7.
8.2.3 Soft key configuration
We have previously described the control panel’s “soft” keys. For Submerged Arc
Welding (SAW) and for Gas Metal Arc Welding (GMAW) welding, the user has the
possibility of setting the function of these keys by selecting from a list of set options.
There are eight soft keys that can be allocated a function.
It is possible to choose between the following options:
S None
S Gas purge / Flux valve
S See set values in the measurement menu
S Relay 1
Sets relay output no.1 on the motor circuit board, which can be used for any
function by the customer.
In the display screen
there are two columns;
one for SOFT KEYS
and one for FUNC-
TION.
SOFT KEYS SETUP
SOFT KEYS FUNCTION
S1 NONE
S2 NONE
S3 NONE
S4 NONE
S1 2ND FUNCT NONE
S2 2ND FUNCT NONE
S3 2ND FUNCT NONE
S4 2ND FUNCT NONE
QUIT
