− 27 −
bi24d1ea
If a data set is already
stored in the selected
location, you will be
asked if you want to
overwrite that set or
not, YES or NO.
WELD DATA MEMORY
1 −
2 −
3 −
4 −
5 − (SAW)
6 −
7 −
SAW: CA: FE SOLID: 3.0 mm
30.0 V: 450 A: 50 cm/min
NO YES
Return to the memory menu using NO.
7.3 Recall
We are going to recall a
stored data set:
Mark the row using the
positioning knob. Press
RECALL.
WELD DATA MEMORY
1 −
2 −
3 −
4 −
5 − (SAW)
6 −
7 −
SAW: CA: FE SOLID: 3.0 mm
30.0 V: 450 A: 50 cm/min
STORE RECALL DELETE
2ND
FUNCT QUIT
Press YES to confirm
that you want to recall
data set number 5.
WELD DATA MEMORY
1 −
2 −
3 −
4 −
5 − (SAW)
6 −
7 −
SAW: CA: FE SOLID: 3.0 mm
30.0 V: 450 A: 50 cm/min
NO YES
